A4.廢鐵回收
Steel Scrap Recycling
廢鐵回收 A4-1.鐵金屬處理設備 A4-1a.SS型固定式油壓剪
A4-1b.SC型固定式油壓剪 A4-2.廢鐵(車)粉粹分離設備
SC Type Stationary Scrap Shear Steel Scrap Processing Plant
A4-1.鐵金屬處理設備FERROUS EQUIPMENT 下載down load
2.粉碎機 SHREDDERS
3.傳統的製造設備,而使用良好的性能和動力來設計
EQUIPMENTBUILT WITH TRADITION AND DESIGNED WITH PERFORMANCE AND POWER IN
MIND
4.機器相片MACHING PHOTOS
5.BSH斷頭台式油壓剪BSH GUILLOTINE SHEARS
6.GS型梱裝/木材/油壓剪 GS BALER/LOGGER/SHEARS
GS型裝有新型先進的油壓系統,快速而且減少循環時間,可增加產能
THE GS IS EQUIPPEDWITH THE NEW ADVANCED HYDRAULICSYSTEM UTILIZING FLOODEDSUCTION
PUMPS, AND IS FAST WITH DECREASED CYCLE TIMES AND INCREASED PRODUCTIVITY
7.最好操作是安全的一種THE BESTOPERATION IS A SAFE ONE
8.機器相片MACHING PHOTOS
9.ABS油壓剪ABS SHEARS
快速和經濟的FAST AND ECONOMICAL
10.TGS成綑機TGS BALERS
高產能和多用途HIGH PRODUCTION AND VERSATILITY
11.TG 型成綑機 TG BALERS
12.SS型邊擠型油壓剪SIDE SQUEEZE (SS) SHEARS
13.機器相片MACHING PHOTOS
14.H562成綑機/木材/油壓剪H562 BALER/LOGGER/SHEARS
高效率HIGH EFFICIENCY
固定式或可移動型STATIONARY OR TRANSPORTABLE
15.銷售和服務SALES AND SERVICE
我們的承諾OUR PROMISE
典型的客戶使用TYPICAL CUSTOMER APPLICATIONS
16.在設計,製造和支持成為廢鋼製程,資源回收和廢料處理設備居於世界領導地位
IS A WORLDWIDE LEADERIN THE DESIGN, MANUFACTURE ,
AND SUPPORT OFSCRAP PROCESSING, RECYCLING, ANDWASTE HANDLING EQUIPMENT
A4-1a. SS型固定式油壓剪 SS TYPE STATIONAY SCRAP SHEAR 下載down load
SS型固定式油壓剪 SS TYPE STATIONAY SCRAP SHEAR
旁邊壓縮油壓剪 SIDE SQUEEZE SHEAR
旁邊壓縮油壓剪 SIDE SQUEEZE SHEAR
標準特性 STANDARD FEATURES
A4-1b. SC型固定式廢鐵油壓剪 SC STATIONARY SCRAP SHEAR 下載down load
旁邊壓縮油壓剪 SIDE COMPRESSION SHEAR
旁邊壓縮油壓剪 SIDE COMPRESSION SHEAR
標準特性 STANDARD FEATURES
性能 PERFORMANCE
油壓單元 POWER UNIT
油壓動力學效率( EHD ) EFFICIENT HYDRAO-DYNAMICS (EHD)
機械管路 MACHINE PIPING
油壓剪框架 SHEAR FRAME
A4-2.廢鐵(車)粉粹分離設備 Steel Scrap Processing Plant 下載down load
A4-2-1
鑒於建造高爐煉鋼成本過高,世界上約50%的鋼鐵系由廢鋼煉造,近年來電爐EAF煉鋼已成為中小型煉鋼的主流,而廢鋼處理能力便成為提升產能的關鍵。
50% of the world’s annual steel yield comes from scrap steel. Since the cost for building a blast furnace for steel making is too high, the smelting from EAF becomes the main stream in medium and mini mill. However, the treatment of scrap steel is the crucial key to steel mill for improving their production capacity and quality.
我們設計的廢鐵(車)回收設備及整個工事規劃,為整個廢鐵(車)處理流程提供解決方案。提升廢鐵(車)處理效率與質量,確保客戶能從處理廢鐵廢鋼中得到最大的利潤是我們對客戶的承諾。
Shredding is a capital intensive process design for the large volume size reduction and
separation of ferrous from non-ferrous and non-metallic materials. We aim to achieve the highest recovery rate as possible which ensure our customers gain maximum revenue from their ferrous and non-ferrous scrap.
預碎機(選配)Pre-Shredder(Optional Equipment)
Typically, Pre-Shredders are capable of processing capacity up to 10-60 tons of scrap materials per hour including:
1.整台汽車(普通狀態),有或沒有引擎,或被壓扁的情況。
Complete cars under “as received”, with or without engines, or flattened condition.
2.家電類例如:家用電器、洗衣機、冰箱等。
”White Goods” i.e., household appliances, washing machines, refrigerators, etc.
3.鐵和鋼廢棄物到正常1/4“(8釐米)的厚度。
Iron and steel scrap up to a normal thickness of 1/4”(8mm).
4.堅硬的大塊物品等。
Hard packed bales, etc.
A4-2-2
預碎機主要用以幫助粉碎機操作員處理其它方面造成的問題,或太過危險不能處理的材料。主要項目通常是重的大包物料,甚至於整台汽車。
Pre-Shredder is primarily designed for helping the shredder operator process materials
that might cause problems or too risky to process. Normally the major items are heavy bales, so iong as they will fit, and whole car body.
特點 Special feature
1.易保養及更可靠的操作、和以每噸成本較低的處理費用來產生廢鐵。
Reliable operation and ease of maintenance of the shredding plant at a lower processing cost-per-ton of scrap produced.
2.耐磨零件是以硬化合金剛在當地鑄造廠的嚴格質量管控下製作。
Wear parts are manufactured from proprietary work hardening steel alloys produced in localfoundry under strict quality control.
3.上部和下部輥輪設計,提供高效率的處理能力。
The upper and lower rollers designed are keys to the effectiveness of the Pre-Shredder.
主碎機 Main-Shredder
主碎機是整個粉碎處理的核心,進料口寬度最大達2.6M可確保整台車都可粉碎,裝填進來的廢鐵料由主碎機擊碎,壓縮到夠小時則由下方格柵孔排出,反之則重複擊碎,壓縮直到可以排出為止。在主軸後方則設有一油壓機構控制開閉的排放門,用於特殊狀況時將不可粉碎的廢鐵排出。
Main-Shredder is a core part of the scrap metal processing plant, the shredder size is to accept scrap materials up to a width 2.6 meter. This ensures that it can process complete cars under”as received” or flattened condition without problems. The in-feed scrap is fragment with high velocity force and continually compress scrap metal untill it is small enough to pass through grate opening. The unshredderable items that pass around the rotor can be discharged from the shredder through the reject door located in the rear wall of the shredder.
A4-2-3
特性 Capability
1.我們設計主碎機的大小為60x104到120x120,產出範圍從25噸-400噸,主馬達範圍從1,250HP-10,000HP。
We offer shredder sizes from 60x104 to 120x120, capacities range from 25-400 tons/hr and
the rotor size ranges from 1,250HP to 10,000Hp
2.負載大,產量高。
Special Feature:Heavy duty design, high capacity.
3.效率高,不易發生故障。
High efficiency and reliability in operation.
4.易於維修保養。
Ease of maintenance and Cost Effective.
5.可遠程控制,避免現場操作的危險。
Available remote control for increasing safety of operation.
集塵系統 De-Dusting System
從主碎機、振蕩器開始,只要是會產生粉塵的部分,就會連接集塵風管,用強大的吸力把較輕的粉碎料、微粒吸進旋風式集塵系統中,運送到粉塵儲存區。作初步的分類並維持工作環境的空氣品質。
Main-Shreder and Vibrator are easy to bring dust into the air while procesing.The high efficiency cyclone will remove a high percentage of the waste materials and convey to the(Auto Shredded Residue ,ASR) area.
1.兩段式獨立系統。
Special Feature. Two stage optimal design.
2.超強吸力旋風式集塵桶。
Super suction Dust Collector.
3.防爆口設計,防止主碎機粉碎過程中產生爆炸而發生損害。
Flame-proof design; in case of any damage from explosion during
篩選系統 Separate and Transfer System
粉碎後的顆粒經由粉碎機下方的振動機及磁選機篩選並由輸送帶輸送,其中非鐵金屬裡含有不少可再次利用高價值金屬,如鋁、銅等。非鐵金屬經過分類後的物質可再由輸送帶運送至該物料堆放位置,進而提高回收經濟效益。
The fragment scrap is transferred from the Undershredder Vibrator to the magnetic separation unit by a rubber belt conveyor. There are many value recyclable metals from the non-ferrous scarp, such as Aluminum, Copper, etc.. Non-Ferrous sorting machine will separate and transfer it via conveyor to the stacking area.
特點 Special Feature
1.區分為非鐵金屬、鐵金屬與廢料輸送帶三大類。
Three major classification:Ferrous, Non-Ferrousand Residue.
2.輸送機皮帶採用耐磨、耐腐蝕、抗酸鹼、及阻燃的多功能複合橡膠。
Conveyor belts are made by durable material which is anti-corrosive, flam-proof and
multi-functional rubber.
3.輸送帶旁並設有走道及爬梯,以利於操作人員檢查與維修。
All conveyors are set up service platform and access ladder in case of maintenance
and monitoring.
A4-2-4
附屬設備 Auxiliary equipments
與許多優秀的在各自領域領先的公司合作,提供渦流系統,磁鐵,感應分揀系統和其他設備。無論您的要求為何,我們可以提供最好的廢舊金屬回收加工廠的設計和解決方案。
Cooperate with many outstanding leading companies in their field. They supply the Eddy Current System, Magnets, Induction Sorting system and other equipment. From the auxiliary to whole plant whatever your requirements, we can offer the best design and solution for Scrap Metal Recycling processing plant.
流程控制 Process Control
可以設定自動控制,讓操作原在安全環境中更輕鬆的進行廢鐵處理,還能節省大量人力,並提高廢鐵回收品質
Process control includes hardware and software to control the system, the operator can remote control the shredding process via Touch screen or control button and make a adjustment of controllable variables of individual equipment, such as the height of Double Feed Roller, feeding speed, etc..
自動控制功能 Automatic Control Functions
自動控制功能比傳統運營商的功能更安全,在監察原料,它能夠有最大限度去驅動電機的性能和控制進料速度增加平均產量,而當手工操作時這幾乎是不可能的。
Automatic control function is safer than the traditional operator function, by monitoring the In-Feed materials it is able to maximize driver motor performance and control the In-Feed speed to increase average production, which almost impossible when it’s on manual operation.
特點 Feature
1.更有效率,易於管理。
More efficiency , ease of management .
2.自動加工控制和駕駛。
Automatic processing control and motoring.
3.節省電能。
Less power consumption.
